Caser Tip For Aluminum Sheet Casting

Caster tip are the key parts of the continuous aluminum trip casting machine which directly effect the quality of aluminum sheets. The Traditional Continuous Sheet Casting Tips can be divided into many types according to different casting machines.

Inquire Now Next Product

Introduce

Caster tips are the key parts of the continuous aluminum trip casting machine which directly affect the quality of aluminum sheets. The Traditional Continuous Sheet Casting Tips can be divided into many types according to different casting machines.

The caster tip of our plant is compounded by ceramic fiber and some other refractory materials. The opening surface and the coating of the working surface are smooth and it can resistant to the corrosion of the liquid aluminum, guaranteeing the purity of the aluminum sheet.

Caster tip for casting with excellent non-wetting properties, low thermal conductivity, high-temperature stabilities, uniform density, smooth surfaces, and close tolerance, is superior products for continuous aluminum strip casting.

Advantages

1. High pure Al-Si material;
2. High hardness, non-stick aluminum, smooth surface, satisfied insulation
3. Ware resistance, non-deform, good protection for sheet surface.

Data Sheet

Density	0.45～0.50g/cm3
Thermal conductivity	< 0.12W/m.k ( 700℃)
Temperature	< 1250℃
Compressive strength	> 0.16MPa
Flexural strength	> 0.06MPa
Coefficient of thermal expansion	2.77×10-6（700℃，m/m. ℃）
Burst factor	17.2～20.7N/mm2

Application

Caster tips are the key parts of the continuous aluminum trip casting machine.

Packing

In plywood case with form.
